24 Gauge Dx51d Zinc Coated Gi Galvanized Steel Sheet
Specification
Product name |
Galvanzied Sheets |
Standard |
SPCC, SGCC, DX51D, Q195, Q235 |
Width |
700-1500MM |
Thickness |
0.3-20mm |
Tolerance |
±2% |
Shipping date |
7-10 days in stock,about 30 days for customized |
Place of origin |
Tianjin,China |
Product Introduction
Advantages of galvanized corrugated sheets
1.Moreover, the cathodic protection effect of zinc can delay the corrosion of the base material, and the anti-corrosion life can reach several decades. The zinc coating thickness of hot-dip galvanized steel sheets is usually 50-300g/m², and their corrosion resistance is significantly better than that of ordinary steel sheets.
2.Excellent processing performance:Supports various processing methods such as stamping, bending, and welding. The elongation of cold-rolled galvanized sheet can reach over 30%, making it suitable for processing complex shapes. Hot-rolled galvanized sheets eliminate the cold-rolling process, reducing production costs by approximately 15%.
3.Compliant with RoHS standards, the trivalent chromium passivation process replaces the traditional hexavalent chromium, enhancing environmental protection performance.
4.Excellent anti-corrosion performance:The zinc coating can effectively prevent steel from coming into contact with corrosive media. In outdoor environments, its service life can reach 50 years (in suburban areas) or 20 years (in coastal areas), and a dense protective film is formed through the principle of sacrificial anode protection.
5.High strength:retains the original mechanical properties of steel and is suitable for load-bearing structures.
Application Cases
Construction
Highway guardrail panels
Automobile body manufacturing
Wall decoration
Roofdrainage system
Manufacture lokers
Package&Shipment
1.Marking requirements:When packaging and bundling hot-dip galvanized steel grating, plates of the same specification should be neatly stacked together, with the side bearing the label or steel stamp placed on the outside for easy inspection. When using packing straps, ensure that there are packing straps on both sides and on all four sides.
2.Moisture-proof and water-proof:Galvanized sheets may be exposed to rain or other liquids during transportation, so moisture-proof and water-proof measures need to be taken. Moisture-proof pads can be laid inside the box or moisture-proof bags can be used to package the goods to ensure that they do not get damp.
3.Transportation route selection:When choosing a transportation route, factors such as the flatness of the road, traffic conditions and road conditions should be taken into consideration. Try to choose a smooth and bumpy road to avoid damage to the galvanized sheet due to poor road conditions.
4.Poisture-proof and water-proof:The packaging should have good moisture-proof and water-proof performance to prevent the galvanized sheet from being damaged by moisture. If the goods are sensitive to moisture, the packaging should be lined with moisture-proof paper.
Package
Shipment
